Frangible Roof Storage Tank

A frangible roof joint forming a flexible gastight connection between a tank shell and a roof comprising an annular link mechanism sealingly secured at or adjacent a first edge thereof to a rim of.

Frangible roof storage tank.

That is of course if the tanks are built according to the rules for frangible roofs. In fact the frangible roof design fulfills the venting requirements due to deflagrations inside tanks for most tank sizes greater than about 35 feet in diameter. A frangible roof joint forming a flexible gastight connection between a tank shell and a roof comprising an annular link mechanism sealingly secured at or adjacent a first edge thereof to a rim of the tank and sealingly secured at or adjacent a second edge thereof to the periphery of the roof. In such tanks the roof to shell joint is intended to fail in the event of overpressurization venting the tank and containing any remaining fluid.

This paper presents the results of an investigation into the frangible joint behavior of tanks designed to api 650 rules. In the event of over pressurization the frangible roof to shell joint is designed to fail before the tank shell or the shell to bottom joint.
